Most data pipelines don't fail loudly. They fail silently, by producing incorrect data.

Six months into managing an insurance data platform, a monthly claims audit revealed a discrepancy. Total claim costs were running 12% higher than the source system.

Root cause: late-arriving data.

Figure 1: Append-only pipeline creates duplicate records for the same claim_id due to late-arriving corrections

Why append-only loading fails

Append-only pipelines assume data never changes.

Append-only pipelines are popular because they are simple to build, easy to scale, and easy to audit. They work well when every record is new and never changes, like logs or clickstream data.

The problem starts when data can change after it is created. In real systems, claims are updated, orders are modified, and transactions are corrected. These updates appear as new records in the pipeline, so it stores both the original and corrected records. Both remain in the table.

Append-only behavior (problem)

Every incoming record is added as a new row. Both the original and corrected records exist simultaneously. Data gets duplicated, and aggregations become incorrect. The result is incorrect numbers with no errors.

Detecting duplicates

python

df = spark.read.format("delta").load("/tmp/delta/claims")
display(df)

df.groupBy("claim_id").count().display()

python

df = spark.read.format("delta").load("/tmp/delta/claims")
display(df)

df.groupBy("claim_id").count().display()

Figure 2: Duplicate detection using GROUP BY highlights records appearing multiple times

The fix: merge and upsert patterns in Delta Lake

Delta Lake's MERGE INTO compares incoming records against the existing table on a business key. When a match is found, the target row is updated. When no match exists, the record is inserted. No duplicates. No correction logic pushed to consumers. Full ACID guarantees.

Merge and upsert behavior (solution)

Corrections update existing records rather than creating new ones. Only one row per business key is maintained at any time. The latest data replaces old data.

MERGE SQL

MERGE INTO delta.`/tmp/delta/claims` AS target
USING updates AS source
ON target.claim_id = source.claim_id
WHEN MATCHED AND source.updated_at > target.updated_at THEN
  UPDATE SET *
WHEN NOT MATCHED THEN
  INSERT

MERGE INTO delta.`/tmp/delta/claims` AS target
USING updates AS source
ON target.claim_id = source.claim_id
WHEN MATCHED AND source.updated_at > target.updated_at THEN
  UPDATE SET *
WHEN NOT MATCHED THEN
  INSERT

Figure 3: Final dataset after MERGE with no duplicate records and correct values

Handling multiple corrections before MERGE: deduplication

Sometimes multiple corrections for the same record can arrive in the same batch. A claim might be updated twice within a few hours, a system might send multiple retries, or a batch load might contain historical corrections. In each of these cases, the same claim_id can appear multiple times in the incoming dataset.

Deduplication in Databricks (PySpark)

python

from pyspark.sql.window import Window
from pyspark.sql.functions import row_number, col

# Define window partitioned by business key
window = Window.partitionBy("claim_id").orderBy(col("updated_at").desc())

# Keep only latest record per claim_id
deduped_df = source_df.withColumn(
    "rn", row_number().over(window)
).filter("rn = 1").drop("rn")

display(deduped_df)

python

from pyspark.sql.window import Window
from pyspark.sql.functions import row_number, col

# Define window partitioned by business key
window = Window.partitionBy("claim_id").orderBy(col("updated_at").desc())

# Keep only latest record per claim_id
deduped_df = source_df.withColumn(
    "rn", row_number().over(window)
).filter("rn = 1").drop("rn")

display(deduped_df)

Watermarking and late-data windows for streaming pipelines

The merge pattern handles batch pipelines cleanly. Streaming pipelines reading from Kafka, Event Hubs, or Kinesis need an additional mechanism: watermarking. A watermark tells Spark how long to accept late data before closing a time window.

This is how watermarking controls late-arriving data in a streaming pipeline. Events arriving within the watermark window (4 days in this example) are accepted and merged. Late corrections arriving on Day 1 and Day 3 are still processed. Events arriving after the watermark boundary, such as the Day 5 event in the diagram, are ignored.

[Figure: Watermark boundary diagram showing Day 0 through Now, with Correction Day 1 and Correction Day 3 accepted and merged, and Event Day 5 dropped as past boundary]

This prevents infinite waiting for late data, excess memory usage, and unbounded state growth. The watermark duration should be based on the business SLA for how late data can realistically arrive.

Example code

python

stream_df = spark.readStream.format("delta").load("/tmp/source")
watermarked_df = stream_df.withWatermark("event_time", "4 days")

python

stream_df = spark.readStream.format("delta").load("/tmp/source")
watermarked_df = stream_df.withWatermark("event_time", "4 days")

The same pattern across industries

Late-arriving data is not unique to insurance. It exists in almost every system where data can be updated after it is created. The solution remains the same: use MERGE based on a business key. Only the key and the conditions change, not the pattern.

Insurance

Claims are often corrected two to four days after initial submission. Updates include changes to payouts, diagnosis updates, or reclassifications of claim type.

Match on: claim_id In some cases: claim_id + line_item_id

Logistics

Shipment statuses change over time as packages are delivered, delayed, or rerouted. Corrections can arrive late from carrier systems.

Match on: tracking_id + event_type

Important: Do not overwrite the entire record. Preserve shipment history.

Financial services

Transactions are adjusted during reconciliation. This includes chargebacks, reversals, and settlements.

Match on: transaction_id

Manufacturing

Sensor data may be corrected after calibration. Historical readings can be updated.

Match on: device_id + time range

How to test for this problem before it hits production

Test 1: Duplicate key test

Send the same record twice, once as an original and once as a correction. Verify that only one row exists and that the final value matches the latest correction.

python

df = spark.createDataFrame([
    ("CLM-1", 1000, "2024-01-01"),
    ("CLM-1", 1500, "2024-01-03")  # correction
], ["claim_id", "amount", "updated_at"])

python

df = spark.createDataFrame([
    ("CLM-1", 1000, "2024-01-01"),
    ("CLM-1", 1500, "2024-01-03")  # correction
], ["claim_id", "amount", "updated_at"])

Expected: only 1 row, with the latest value of 1500.

python

from pyspark.sql.window import Window
from pyspark.sql.functions import row_number, col

window = Window.partitionBy("claim_id").orderBy(col("updated_at").desc())
df_latest = df.withColumn("rn", row_number().over(window)) \
    .filter("rn = 1") \
    .drop("rn")

python

from pyspark.sql.window import Window
from pyspark.sql.functions import row_number, col

window = Window.partitionBy("claim_id").orderBy(col("updated_at").desc())
df_latest = df.withColumn("rn", row_number().over(window)) \
    .filter("rn = 1") \
    .drop("rn")

Test 2: Out-of-order test

Send the correction first, then the original record. Verify that older data does not overwrite newer data.

python

df = spark.createDataFrame([
    ("CLM-2", 1500, "2024-01-03"),  # newer
    ("CLM-2", 1000, "2024-01-01")   # older
], ["claim_id", "amount", "updated_at"])

python

df = spark.createDataFrame([
    ("CLM-2", 1500, "2024-01-03"),  # newer
    ("CLM-2", 1000, "2024-01-01")   # older
], ["claim_id", "amount", "updated_at"])

Expected: the record with the later updated_at timestamp should win regardless of arrival order.

Test 3: Multiple corrections test

Send multiple updates for the same record within a single batch. Verify that only the latest record is used and that no merge errors occur.

Test 4: Watermark boundary test (streaming)

Send one event within the allowed time window and one event just outside the window. Verify that the valid event is processed and the late event is either ignored or routed to a dead-letter destination.

python

df.withWatermark("event_time", "5 days")

python

df.withWatermark("event_time", "5 days")

Final takeaway

Late-arriving data is not an edge case. It is a fundamental property of real-world systems.

Pipelines don't fail loudly. They fail silently by producing incorrect data. That is why handling late data with MERGE, deduplication, and watermarking is essential for building reliable data pipelines.
